FloorDeck 32 - High Performance Structural Acoustic Floating Floor System

SRU FloorDeck 32 is a High Performance acoustic floor system designed to cut back on both airborne and impact noise. It’s the perfect choice for floors in poor condition that need to be replaced.

The SRU FloorDeck 32 provides both structure and acoustic protection and can be laid directly to the joist or laid over a an existing concrete floor thus saving any height restrictions. An excellent product for Architects and property Developers when converting properties into HMO's, designing new builds, property renovations and gymnasium floors. Complies to  Part E Regulations (Alternative to Monarfloor Tri-Deck)

Finishes:

• Carpet
• Wood
• Vinyl
• Tiles

Benefits

·       Full support of floor loadings

·       Superior performance from the recycled foam used, which represents excellent impact improvement.

·       Fire resistance. Fully foam fire tested to BS4790 and MLV30 Mass Loaded Vinyl fire tested to Dfl-s1

·       Guaranteed quality

·       Fully Document E compliance: FloorDeck 32 is suitable for many different building systems

Flanking transmission

Acoustic noise can sometimes leak through adjacent walls and ducts, in a phenomenon known as flanking transmission. FloorDeck 32mm, combined with Acoustics Tape (a flexible polyethylene seal) can help to cut this down.

Performance

Based a ceiling construction of a ceiling/floor construction of 60kg/m3 insulation between joist & plasterboard ceiling

·       DnT,w + Ctr: 46dB

·       LnT,w : 55dB

Dimensions (in mm)

·       Sheet Size: 2400mm x 600mm

·       Thickness: 32mm

·       Weight 30.5kg

·       Density 22.8kg/m2
